60223-GLC WORKSURFACE MOUNTED ADJUSTABLE ARM WITH LAPTOP CLAMP

The 60223GLC combines the adjustable arm with a laptop clamp to securely hold your laptop in place.

Weight capacity for this system is 5-15 lbs. which is usually sufficient for most all laptops.  If you require more weight capacity, please contact CPS.

The adjustable arm provides vertical positioning from the vertical (Up) to horizontal (down) positions.  The laptop mounting bracket provides left / right pivot and forward / back tilt.

Color choices are light gray or black.

CPS can provide poles that are worksurface, floor or ceiling mounted.  Pole Options

Reference the ORDER GUIDE tab in the section below to find the specific arm configuration that meets your application requirements.





Modular Design
These arm systems consist of modular components that can be added or removed to meet the users specific application requirements.  Supporting your LCD display, keyboard, laptop or some other type of equipment can be accomplished with a variety of arm configurations found throughout this product section.

Material
Manufactured using high quality aluminum die castings and aluminum extrusions.  Built for commercial and industrial applications in a wide variety of industries, including manufacturing, electronics, medical, military, government, schools and universities.

Finish
Industrial quality powder coat finish.  Most components available in light gray or black.

Range of Motion
The #60223-GLC Adjustable Arm: Left / Right Pivot, Up / Down adjustment. Laptop Clamp: Left / Right Pivot, Forward / Back Tilt.

Easy to Install
Installation takes less than 15 minutes using common hand tools.



Part Number:
60223-GLC (See Order Guide tab for specifics)

Weight:
5-15 lbs.

Color/Finish:
Black or Light Gray Powder Coated Finish

Warranty:
1 year from date of purchase

Shipping Method:
FedEx or UPS
DESCRIPTION WEIGHT CAPACITY PART NUMBER
Worksurface Mount (Grommet Pin), Adjustable Arm + Laptop Clamp, Light Gray 5-15 60223GLC-AL-G
Worksurface Mount (Grommet Pin), Adjustable Arm + Laptop Clamp, Black 5-15 60223GLC-AL-B
Mouse Tray, Black Only (Optional)   P24-12-10-B

  If you need this arm configuration with the #25-25 Die Cast Base, please contact CPS for part number and pricing.

  • Platform Mount (21-14)
  • Laptop Clamp (24-06)
  • Adjustable Arm (22-04-3)
  • Grommet Pin (25-22)
  • Optional Mouse Tray (P24-12-10-B)
  • Hardware
